Anzugsbolzen MAS 403 BT (JIS B 6339 )
Pull studs MAS 403 BT (JIS B 6339 )
Tirettes MAS 403 BT (JIS B 6339 )
Bestell-Nr.
Order no.
Rfrence M l1 l2 l3 d1 d2 d3 d4
305.20.45
M12
45°
43
23
18
11
7
12,5
–
305.20.60
M12
60°
43
23
18
11
7
12,5
–
405.20.45
405.20.60
405.20.90
M16
45°
60
28
15
10
17,0
–
M16
60°
60
35
28
15
10
17,0
–
M16
90°
60
35
28
15
10
17,0
–
505.20.45
505.20.60
505.20.90
M24
45°
85
45
35
23
17
25,0
–
M24
60°
85
45
35
23
17
25,0
–
M24
90°
85
45
35
23
17
25,0
–
Ohne Durchgangsbohrung, ohne O-Ring
Sealed, without O-ring
tanche, sans joint torique
7
406.20.45
406.20.60
406.20.90
M16
45°
60
35
28
15
10
17,0
4,0
M16
60°
60
35
28
15
10
17,0
4,0
M16
90°
60
35
28
15
10
17,0
4,0
506.20.45
506.20.60
506.20.90
M24
45°
85
45
35
23
17
25,0
6,0
M24
60°
85
45
35
23
17
25,0
6,0
M24
90°
85
45
35
23
17
25,0
6,0
Mit Durchgangsbohrung, inkl. O-Ring
With drill through, incl. O-ring
Perce, avec joint torique
